NFRC Aluminum Tilt And Turn Window Energy Efficient Inward Good Water Tightness For Apartment Construction Projects In North America

Product Description

We are a professional manufacturer of aluminum tilt & turn windows, the European-style dual opening windows widely used in residential and commercial projects. Featuring 6060-T6 thermal break profiles, multi-chamber construction and a multi-point locking tilt & turn hardware system, our windows offer two opening modes: full casement opening for ventilation and cleaning, and tilt mode for draft-free, child-safe ventilation. Fully customizable in size, color, glazing and hardware, suitable for apartments, villas, high-rise buildings, offices and renovation projects. NFRC Certified, OEM/ODM supported. Contact us for a quotation, or send your drawings for a custom quote.

Key Features

• Dual Opening Modes — tilt mode opens the top inward for secure, rain-safe ventilation; turn mode opens the sash fully for maximum airflow and easy cleaning.
• European Tilt & Turn Hardware — multi-point locking espagnolette with integrated tilt mechanism and 304 stainless steel hinges for smooth, durable operation.
• Multi-Point Locking Security — locking points around the entire sash perimeter effectively resist prying and break-in attempts.
• Thermal Break Energy Efficiency — PA66GF25 thermal break strips and multi-chamber profiles achieve a U-Factor as low as 1.0 W/(m²·K).
• Excellent Sealing — multi-seal EPDM gaskets deliver Class 8 air permeability and Class 6 water tightness.
• Child-Safe Ventilation — tilt mode limits the opening gap to prevent children from falling out while still allowing fresh air in.
• Easy Cleaning & Maintenance — the inward opening sash allows both sides of the glass to be cleaned safely from inside, ideal for high-rise buildings.
• Full Customization — size, color, glazing and hardware fully customizable; OEM/ODM supported.

Specifications

Materials & Finish

• Aluminum profiles: 6060-T6 aluminum alloy — high tensile strength, corrosion resistant, long service life

• Surface finishes: anodizing (AA15–AA25), powder coating (≥ 60μm), PVDF coating, wood/stone grain transfer — strong adhesion, weather and UV resistant

• Thermal break strips: PA66GF25 nylon (14.8–34.8mm) — high strength, stable insulation performance

• Gaskets: EPDM composite gaskets, -40°C to 120°C, aging resistant

• Hardware: European tilt & turn hardware — multi-point espagnolette, concealed hinges, zinc alloy handles with optional child safety lock

• Glass: automotive-grade float glass; tempered, laminated, Low-E, argon-filled IGUs optional

• Processing: CNC double-miter saw cutting (±0.5mm accuracy), corner crimping with adhesive, 100% inspection of every assembled window

Assembly & Installation

Installation steps

• Measure the opening — verify actual opening dimensions, level and plumb

• Install the frame — fix with expansion bolts / connectors; adjust level and plumb to within 2mm

• Hang the sash — install the sash on the tilt & turn hinges and adjust for smooth tilt and turn operation

• Waterproofing — fill gaps between frame and wall with foam, apply weather-resistant sealant with a drainage slope outside

• Final adjustment — check both opening modes and locking points, remove protective film and clean

Maintenance

• Clean drainage holes and tracks quarterly to prevent blockage and water pooling

• Lubricate the espagnolette, tilt mechanism and hinges with neutral oil every six months

• Check the child safety lock and gaskets for wear; replace as needed

• Avoid acidic or alkaline cleaners on profile surfaces

Applications

• Residential apartments & communities — the European standard choice for homes (keywords: tilt and turn windows, apartment windows)

• Villas & townhouses — large dual-opening windows for ventilation and unobstructed views

• High-rise buildings — inward opening allows safe glass cleaning from inside

• Office buildings — controlled tilt ventilation with high air tightness

• Hotels & guesthouses — quiet, safe ventilation for guest rooms

• Schools & kindergartens — child-safe tilt ventilation in classrooms

• Renovation & window replacement — upgrade to European-style dual-opening windows

• Balconies & partitions — tilt & turn units combined with fixed glazing

Customization

• Size: non-standard sizes produced from drawings; arched and special shapes available

• Color: per RAL chart; wood grain, stone grain, dual-color inside/outside

• Glazing: thickness, air space, Low-E, laminated, tempered, frosted, built-in blinds

• Hardware: handle color and lock type, child safety lock, optional security grade

• Opening mode: tilt-first or turn-first handle options
• OEM/ODM service: private label, logo printing, custom packaging, new products developed from customer drawings

Certifications

• Compliant with GB/T 8478 Aluminum Alloy Windows national standard

• ISO 9001:2015 quality management system certified

• CE certified (EU market)

• NFRC energy performance certified (N orth America)

• Third-party test reports from SGS / TÜV available on request

• Factory QC: each batch ships with an inspection certificate

Packing & Logistics

• Inner packing: each window wrapped in EPE foam with protective film

• Outer packing: heavy-duty carton or wooden crate with reinforced corners for long sea freight

• Export crates: fumigation optional, compliant with ISPM 15

• Lead time: 15–25 days standard, 25–35 days custom (subject to order confirmation)

• Shipping: FCL / LCL by sea, air freight, international express

• Trade terms: FOB / CIF / EXW / DDP

• Loading port: 【Qingdao】

Reviews & Cases

Reviews

• “The tilt function is brilliant for our nursery — ventilation without any safety worry. The hardware feels solid and premium.”
• “Ordered 200 units for a residential project in Europe. Hardware passed local certification and installation was straightforward.”
• “Inward opening makes cleaning so much easier on our 8th floor apartment. Thermal performance is excellent.”

Cases

• Project name: Urban Apartment Aluminum Tilt‑and‑Turn Window Project

• Location: Warsaw / Poland

• Scale: 1680 m² window area / 940 units

• Configuration: 92 series thermal‑break aluminum profile + 6+18A+6 Low‑E insulated glazing + 1500*2200mm glass panel size

• Customer feedback: High‑performance windows meet local energy‑saving standards and bring comfortable living experience for end users.

Service

• Samples: free sample windows available before ordering
• Design support: free drawing review, hardware selection and detailed design
• Quick response: inquiries replied within 24 hours; after-sales issues within 48 hours
• Warranty: 3 years on profile structure, 3 years on hardware (per company policy)
• Installation support: installation video and manual provided; on-site technical guidance available
• After-sales: long-term spare parts supply, lifetime parts service
• Quality commitment: every window inspected before shipment; no defective products leave the factory

FAQ

Q1: What is the difference between tilt & turn and casement windows?
A: Tilt & turn windows offer two opening modes — tilt for secure, rain-safe ventilation and full turn opening for cleaning and maximum airflow — while casement windows open only one way.

Q2: Can the window be cleaned from inside?
A: Yes. In turn mode the sash opens fully inward, allowing both sides of the glass to be cleaned safely from inside — ideal for high-rise buildings.

Q3: Is the tilt mode safe for children?
A: Yes. In tilt mode the opening gap is limited to approximately 10–15cm, preventing children from falling out while still allowing fresh air in. Child safety locks are also available.

Q4: What is the minimum order quantity (MOQ)?
A: Custom MOQ depends on configuration — confirm with our sales team.

Q5: What is the production lead time?
A: Around 15–25 days for standard windows and 25–35 days for custom orders; partial shipments can be arranged for large orders.

Q6: What is the maximum opening sash size?
A: Opening sashes are generally produced up to about 1800mm wide × 2500mm high, subject to hardware load capacity and wind load calculation.

Q7: Do you support OEM/ODM?
A: Yes. We offer private label, logo printing, custom packaging, and new product development from customer drawings.

Q8: What is the warranty? How is after-sales handled?
A: 3 years on profile structure and 5 years on hardware. Report issues with photos and we will provide a solution within 48 hours.

Q9: What glazing options are available?
A: Double glazing, triple glazing, Low-E, laminated, tempered, frosted and built-in blinds. We can recommend the right configuration for your local climate.

Q10: How do you guarantee quality?
A: We use qualified suppliers for profiles, glass and hardware, run QC throughout production, and inspect every window before shipment with a certificate of conformity. Test reports are available.

Q11: Can I get a sample?
A: Yes. Samples / sample windows are available free or at cost (freight paid by customer); the sample fee is deductible from the first order.
